One Side Penumatic Tip Dresser Using Compressed Air For Grinding Electrode Tips

Brand Name : BLM

Model Number : CDY-1

Place of Origin : China

MOQ : 1 set

Price : USD280.-/set

Payment Terms : T/T, D/A

Supply Ability : 100 sets per week

Delivery Time : 7~10 working days

Packaging Details : packed with wooden case

name : tip dresser

application : grinding

field : spot welding

material : alloy

used for : electrode cap

Customized : Yes

Model : CDY-1

Accessory : cutter and holder

Features : protable type

Power : compressed air

Contact Now

Penumatic Tip Dresser Using Compressed Air for Grinding Electrode Cap

Tip dresser includes tip dresser tool,cutter blade,cutter holder. All kinds of standard tip dresser cutter blade can be offered by our company. Customized tip dresser cutter according to your drawing can also be satisfied.It is powered by compressed air.Its rotating speed can be around 1300RPM.Tip dresser helps maintain weld consistency and quality in spot welding. Repeated exposure to high temperature will make copper electrode tip geometry after a period of welding. Tip dresser can reset the electrode shape to help welding performance meets the precise specifications as requirements.

Main Specifications

Model	CDY-1
Power	Compressed air
The Biggest diameter of electrodes(mm)	Dia18mm
Turnover(rpm)	1300
Diameter(mm)	7.6-10.0mm
Install model	PT-1/4
Weight(kg)	1.8kgs
